Low-voltage storage battery Floor standing For home14.3/16K
The Low-voltage storage battery ELESHELL14.3K and ELESHELL16K deliver up to 16.1 kWh capacity and 10.24 kW output. And they ensure stable performance with LFP cells and 51.2 V nominal voltage. They achieve over 8000 cycles at 80% depth of discharge, so they provide long service life and lower costs. Moreover, they support up to 15 parallel connections and integrate RS232, RS485, and CAN communication. So they connect easily with multiple inverters. With IP54 protection and international certifications, they offer reliable and scalable home energy storage.
Brand:LeFu New Energy
Model :LF-ELESHELL 14.3/16K
Nominial Voltage:51.2V
Operating Voltage Range:46.4~57.6V
Max.Output Current:140/200A
Cycle life: 6000Cycles
Shipping Port: Shenzhen
Description
The ELESHELL14.3K and ELESHELL16K deliver low-voltage, floor-standing lithium battery solutions, and they combine up to 16.1 kWh capacity with 10.24 kW output, so they meet diverse residential energy needs. They use advanced LFP cells, and they maintain 51.2 V nominal voltage, so they ensure consistent performance and long service life. Because they achieve more than 8000 cycles at 80% depth of discharge, they extend reliability and reduce long-term costs.
Moreover, the modular design supports up to 15 parallel connections, and it allows users to expand capacity flexibly and efficiently. At the same time, RS232, RS485, and CAN communication enable smooth integration with multiple inverters, and they also simplify installation. In addition, IP54 protection and natural cooling enhance durability, while certifications such as UN38.3, CE, IEC62619, and ROHS strengthen safety and compliance. Therefore, the ELESHELL series delivers reliable, scalable, and efficient home energy storage, and it offers a practical solution for modern households.
| Model ELESHELL14.3K ELESHELL16K | ||
| Battery Capacity(wh) | 14336 | 16076 |
| Number of cells | 1P8S*2 | |
| Cell Type | LFP | |
| Nominal Voltage (V) | 51.2 | |
| Operating Voltage Range (V) | 46.4~57.6 | |
| Max.Charge /Discharge Current (A) | 140 | 200 |
| Continuous Charging/Discharging Current (A) | 140 | 200 |
| Max.Power（W） | 7168 | 10240 |
| Dimension (H*W*D mm) | 750*412*235 | 750*412*235 |
| Weight（KG） | 119 | 121 |
| Operating Temperature Range（℃） | 0-55 | |
| Temperature.Control | natural cooling | |
| Max.Number of Parallel | 15 | |
| Communication | RS232 / RS485 / CAN | |
| Cycle Life (80%DOD,25℃) | >8000 | >8000 |
| Ingress Protection Rating | IP54 | |
| Installation | floor mounting | floor mounting |
| Relative Humidity | ≤95%rh | |
| Humidity of storage environment | ≤95%rh | |
| Max. Operating Altitude (m) | ≤3000m | |
| Storage Temperature | ≤25℃，12 months；≤35℃，6 months；≤45℃，3 months | |
| Certification | UN38.3,CE-EMC,IEC62619,MSDS,ROHS | |
